How often does the lining of a waste incineration plant need to be renewed?

The main wear zones – combustion chamber, grate transition and hopper area – are typically partially renewed every 1–3 years during the annual outage. A complete relining of the combustion chamber is required every 5–8 years. The exact intervals depend on the waste composition and plant operation.

What is the difference between a refractory and an acid-resistant lining?

Refractory linings protect against high temperatures and thermal wear in the combustion chamber. Acid-resistant linings are used in flue gas cleaning, where aggressive acids (hydrochloric acid, sulphuric acid) attack the lining at lower temperatures. The two systems require different materials and installation techniques.

Can refractory work be carried out while other trades are working during the outage?

Yes, we coordinate our work closely with the overall outage planning. Our teams work in parallel with other trades and coordinate on site with the outage management. Through multi-shift operation we make optimum use of the available time windows.

Do you also offer services for flue gas cleaning systems?

Yes, in addition to refractory linings in the high-temperature area, we supply acid-resistant linings for scrubbers, stacks and other components of the flue gas cleaning system. This includes both brick-built and coated acid-protection solutions with materials such as graphite, PTFE or acid-resistant bricks.

Fire resistance for incineration and energy generation

Energy / Incineration / Boilers

Incineration plants and boilers are subject to extreme thermal and chemical loads. We supply refractory and acid-resistant linings that withstand aggressive flue gases and high temperatures – for maximum plant availability.

Enquire about a project Call now

80+

Incineration plants serviced

1,300 °C

Max. operating temperature

24/7

Emergency standby

20+

Years in plant engineering

Industry expertise

Refractory construction for Energy / Incineration / Boilers

Incineration and boiler plants form the backbone of thermal energy generation and waste recovery. The refractory lining must withstand extreme loads: temperatures up to 1,300 °C, aggressive flue gases with high chloride and alkali contents, and erosive ash deposits place the highest demands on the lining.

SBS Refractory Service is an experienced partner for operators of waste incineration plants, biomass power plants, thermal recovery plants and industrial boiler plants. In addition to conventional refractory linings, we also supply acid-resistant linings for flue gas cleaning systems and scrubbers – a decisive factor for plant availability.

Our services range from complete relining and annual outage maintenance to emergency service. We coordinate all work with your outage planning and, where required, work in multi-shift operation to limit downtime to the technically necessary minimum.

Typical challenges

Chemical attack by chlorides, alkalis and heavy metals in the flue gas destroys the lining
Erosion by abrasive fly ash and slag particles in the combustion chamber and flue gas passes
Slagging and deposit formation from low-melting ash constituents in biomass fuels
Corrosion of membrane walls and boiler tubes requires special protective coatings
Strict emission regulations require intact acid-protection linings in the flue gas cleaning system

Furnace types
